Slim, fast, fantastic.

Specifications

Dimensions: 23 x 7.5 x 27.5 mm

Weight: 0.42 oz (12 g)

Rated Voltage: DC 7.4V

Voltage Range: DC 4.8 – 8.4V

Output Shaft Spline: 15T, 4mm

Position sensor: Potentiometer

Motor:  Coreless DC

Working Frequency: 1520µs/333KHz

Pulse Range: 900µs-2100µs

Programmable: Yes

Case Material: Aluminium

Gear Set Material: metal gears

Holding Torque

Holding Torque @ 6.0V: 4.5 kg·cm

Holding Torque @ 7.4V: 6.0 kg·cm

Holding Torque @ 8.4V: 6.5 kg·cm

No-load Speed

No-load Speed @ 6.0V: 0.13sec/60°

No-load Speed @ 7.4V: 0.10sec/60°

No-load Speed @ 8.4V: 0.09sec/60°

CAD data (vertical):
CAD data (horizontal):
