The strong crankshaft, ball bearings and needle bearings insure a long life time. This engine was developed having in mind mainly to be used in the industry. The rear out put shaft is a standard feature  and allows to fit alternators, electric starters and starter / alternator units. The manually operated compression release valves are standard as well and allows an easy starting of the engine. The ½” square end of the propeller disc supports  the use of an external electric starter.

TS –Version ( Twin Spark , 2 spark plugs per cylinder ) convinces with a low idle and softer running characteristic.  All boxer engines with this set up have a better reliability. In case 1 ignition will fail the 2^nd. ignition - which operates autonomously – allows the engine to run further with reduced RPM ( 200 – 300).

The micro processor controlled igniton allows to easy start  the engine. The programmed timing curve is laid out for the engines and guarantees a good running characteristic in all RPM – ranges. An out put signal to monitor RPM is standard as well as a LED showing the status of the ignition. The voltage range of the standard ignition : 6V – 8,4V ( 2 cell LIPO battery ).

Techn. specifications
